From Volume to Value: The Strategic Case for Integrated Mine Planning
How integrated mine planning replaces siloed optimisation with a single value-based framework , using MILP, dynamic cut-off grades, and skin analysis to move beyond undiscounted pit shells toward an NPV-driven plan that connects the pit to the market.
Most mine plans optimise each department independently. The result is a plan that looks right from every angle and leaves enterprise value on the table. Integrated mine planning replaces functional silos with a single value-based framework , where every decision is evaluated against its contribution to the whole system, not just one team’s KPI.
Siloed Planning vs. Integrated Planning
The difference is not intent , it is structure. Integrated planning uses a single MILP engine to model the complete value chain on one platform, with NPV as the primary directional guide across every discipline.
Geology
Siloed: delivers a block model and hands it over. Integrated: block model attributes drive cut-off grades, blending constraints, and recovery assumptions directly within the schedule optimiser.
Mine Planning
Siloed: produces a schedule to maximise tonnes or meet a budget target. Integrated: schedule is an output of the MILP; sequencing is determined by discounted value, not volume.
Processing
Siloed: uses fixed throughput assumptions and flat recovery factors. Integrated: throughput is a dynamic constraint; recoveries are linked to ore attributes from the block model.
Capital Decisions
Siloed: expansions are baked-in milestones tied to historical decisions. Integrated: every expansion is a decision variable validated against the system’s current ability to monetise new capacity.
Market and Logistics
Siloed: post-processed after the mine sequence is locked. Integrated: blending windows, product specifications, and logistics constraints are inside the optimisation scope from the start.
Finance
Siloed: builds a separate financial model from the schedule output. Integrated: NPV is the objective function; the time value of money is built into every scheduling decision.
Why Optimisation Silos Destroy Value
Siloed planning is rarely the result of poor intent. It is the natural outcome of functional experts working within the confines of their own technical domains, timelines, and KPIs. The failure modes are consistent across operations.
Conflicting Objectives
Different teams optimise for different metrics , total tonnes, head grade, mine operating cost, concentrate grade, or metal recovery. Without a single value objective, the plan lacks a cohesive direction.
Hidden Assumptions at Interfaces
Gaps between departments produce diverging planning assumptions. Mine planners use different recovery factors than the process plant. Throughputs are modelled as fixed rates rather than dynamic tonnes per hour. These mismatches undermine the entire plan.
Static Constraints
Operational constraints are treated as fixed "givens" or historical habits rather than as limited capacity to be allocated to the highest-value use. Capital expansions gain their own inertia and are never re-validated against the current plan.
Bolted-On Strategies
Blending, haulage optimisation, and stockpiling are post-processed after the mining sequence is defined, rather than being central to the schedule optimisation. This hides the strategic trade-offs and reduces enterprise value.
Plan Instability and Rework
The preferred plan changes significantly when minor adjustments are made to input assumptions. Schedules require constant revision because a constraint , tailings capacity, a logistics bottleneck , is disputed late in the process. Results are reverse-engineered to match a pre-conceived narrative.
The MILP Approach: Nothing Off the Table
Mixed Integer Linear Programming models the mine as a fully integrated system. Every component of the value chain is evaluated simultaneously, across multiple years, to maximise NPV while honouring all defined constraints.
Single Value Objective
NPV is the primary directional guide. In the strategic space, nothing is "off the table" , all potential solutions are judged equally based on their ability to deliver discounted value to the enterprise.
Capacity Allocation, Not Volume Targets
The model identifies binding constraints , mill hours, tailings capacity, rail capacity, capital availability , and allocates them to the highest-value use in each period rather than treating them as fixed maximums.
Dynamic Cut-Off Grade
Cut-off grades and stockpiling strategies are optimised within the schedule, not pre-set. The model determines which material to mine, process, stockpile, or leave in the ground based on the total system value in each period.
Capital Decisions as Variables
Expansion timing and scale , fleet increases, crusher relocations, plant debottlenecking , are active decision variables validated against the current set of assumptions and constraints, not baked-in historical milestones.
OP/UG Transitions Solved Simultaneously
Open-pit to underground transitions involve capital timing, access development, and competing ore sources. MILP evaluates these decisions system-wide, preventing locally optimal pit shells from destroying enterprise value at the transition.
Explicit Opportunity Cost
When the model selects a specific pathway, the displacement or cost elsewhere in the system becomes visible. This transparency supports clearer plan communication and robust scenario testing.
Beyond Pit Shells: Skin Analysis and Discounted Value
Pit optimisation tools such as Whittle and Pseudoflow define the economic limits of a deposit , but they produce undiscounted value contours. They cannot schedule or account for the time value of money. Treating these shells as an “optimised” final design is one of the most common errors in strategic mine planning.
RF1 is Rarely the Maximum NPV Shell
Revenue Factor 1 provides the highest total undiscounted cash flow , not the highest NPV. A final phase requiring five years of pre-strip delivers its ore at a discount factor of ~0.56 at 10%. If early waste costs exceed the discounted ore value, that phase destroys NPV regardless of its undiscounted value.
Skin Analysis: Incremental Phase Value
Skin analysis evaluates the incremental DCF value of each additional phase width. The goal is to find the point of diminishing returns , where the next pushback reduces enterprise value , and to prevent earlier phases subsidising the “sins” of the final mining phase.
Smaller Pits, Higher NPV
In practice, the NPV-optimised shell is almost always smaller than RF 1. By evaluating incremental margin at each pushback, integrated planning avoids over-mining low-value material that looks attractive on an undiscounted chart but destroys value when discounted.
Shells as Spatially Compliant Phases
The practical output of pit optimisation is not a final design , it is a set of spatially compliant mining phases that the schedule optimiser can choose to mine, process, stockpile, or leave in the ground based on total system value.
Blending Drives Shell Selection
For products with shipping contaminants , phosphorus or alumina in iron ore, basicity ratios in nickel , pit shells defined by a single revenue attribute risk ignoring the impact of blending constraints on system value. Scheduling is required to evaluate these interactions.
NPV as Direction, Not Absolute
NPV should be treated as a directional guide, not an absolute success metric. A successful plan aligns corporate objectives with operational practicality. A sub-optimal tactical detail is not worth fighting if it distracts from the broader enterprise objective.
The Pathway to Value
The Pathway to Value is the foundational narrative required to achieve the best value from an asset. It sequences the key decisions and constraint relaxations required to deliver the highest risk-adjusted mine plan , linking phases, expansions, and operating policies directly to value outcomes.
Mining Phase Sequencing
The start and finish times for each phase or pushback, and the rationale for the sequence , which phases bring high-value material forward without making the plan fragile or overly sensitive to assumption changes.
Active Constraints by Period
A clear identification of which constraints are binding in each scheduling period , mill hours, tailings capacity, bench sink rates, rail capacity , and whether a known expansion pathway exists to debottleneck them.
Dynamic Cut-Off Grade Evolution
The evolution of stockpiling and processing cut-over grades for each period, reflecting the changing opportunity cost of ore as the mine transitions through its phases and constraints shift.
Fleet and Infrastructure Milestones
Timing for primary mining fleet replacement or expansion, tailings dam raises, civil works, and the optimal point for mill upgrades, additional milling capacity, or changes in grind size , each validated against incremental value.
Future Work Roadmap
No plan is perfect. Documenting known compromises and areas for technical refinement in the next iteration ensures that even when a preferred plan moves forward as-is, the business has a clear record of what will be improved in the next planning cycle.
Case Studies
The practical value of an integrated approach is best seen when applied to real operations. These case studies illustrate how the “nothing off the table” philosophy navigated strategic challenges that siloed planning cannot resolve.
Diamonds: Portfolio vs. Asset Optimisation
For these Tier-1 diamond assets, local optimisation at the mine level threatened broader business value. Staging open-pit phases against underground development within narrow marketing limits created a massive number of development pathways. IMC built an integrated MILP model linking every production unit directly to downstream marketing constraints , making the opportunity cost of each sequence explicit and defining the strategic triggers for plant upgrades and underground development.
Iron Ore: Product Quality, Permitting and Tailings
In this iron ore system, the plan was dictated by the intersection of product strategy, milling capacity, and tailings capacity. Constraints were moving targets: increased ore hardness was impacting both crushing and flotation throughput. IMC used the MILP engine to evaluate whether a new greenfield mine or brownfield debottlenecking delivered more value, replacing the traditional volume-based plan with a Pathway to Value ranked by incremental NPV versus incremental capital.
Platinum: Optimising a Behemoth
This complex platinum system involved 40 open-pit options and 150 underground alternatives feeding multiple concentrators and off-site refineries. The sheer number of permutations made manual sequencing impossible. IMC integrated the OP/UG transition with stope cut-off grade strategies, concentrator and refinery expansions, and mining fleet in a single model , identifying a transition strategy that synchronised open-pit and underground development for the life-of-mine.
Laterite Nickel: A Blending and Logistics Challenge
Five mining centres, 150 pits, mountainous terrain, and an offshore refinery requiring strict blending windows for Ni grade, Fe:Ni ratios, and MgO:SiO2 basicity. IMC integrated backfilling sequences and haulage route optimisation directly into the value optimisation, providing period-by-period cut-off grade and blending guidance that honoured the plant’s window of acceptance while maximising enterprise NPV.
Download the Full White Paper
The complete paper covers the strategic case for integrated mine planning, the MILP methodology, skin analysis, the Pathway to Value framework, and four detailed case studies across diamonds, iron ore, platinum, and laterite nickel.
Five Pillars of Integrated Planning
To move beyond static, siloed planning, every mine plan must be built on these foundations:
- Establish a Single Truth. Agree on one value objective and a single set of assumptions across functional teams to eliminate conflicting goals.
- Manage Capacity, Not Tonnes. Identify binding constraints , mill hours, tailings capacity, transport logistics , and treat them as allocatable maximums rather than fixed givens.
- Integrate Early. Bring blending, stockpiling, and downstream constraints into the optimisation scope before the mining sequence is locked in.
- Incremental Value. Use skin analysis and discounted cash flow to ensure that current cash flows are not subsidising the sins of the final mining phases.
- Communicate the Narrative. Tell the story of the plan through its key development milestones and its roadmap for future refinement.
Integrated strategic planning converts technical complexity into strategic clarity. Rapidly evaluating 10 to 20 NPV-guided scenarios provides the strategic direction required by the business and the context for tactical plans and budgets. Every decision made is in the context of long-term business value.
